JIL3-ASH-DE664-R

JIL3-ASH-DE664-R
JIL3-ASH-DE664-R
JIL3-ASH-DE664-R

Specification

Construction Bolt-on Neck
Body Ash
Neck Maple U-Shape
Fingerboard Rosewood
Scale 26.14" (664mm)
Frets 24F Jumbo C.F.S.
Tuners GOTOH® SG381-07 MG-T
Bridge FB-S05
Tailpiece -
Hardware Color Black
Pickup (Neck) FISHMAN®M 36-AB1
Pickup (Middle) -
Pickup (Bridge) FISHMAN®M 36-CB1
Controls 1Volume w/ Push-Pull SW (Voice 3-Split), 1Tone w/ Push-Pull SW (Voice 1/2), 3Way Toggle SW
Body Finish Open Pore Matte
Strings D'Addario EXL116 (.011-.052)
Others Factory Tuning : DropC (1D, 2A, 3F, 4C, 5G, 6C)
Accessories Premium Soft Case
Color OPB (Open Pore Black) / OPW (Open Pore White) / OPOG (Open Pore Olive Green)

Features

Circle Fretting System (C.F.S.)

All FGN guitars and basses come with a unique Circle Fretting System (C.F.S.). It was created by FGN based on an idea to offer better pitch and articulation than conventional guitars and basses. All frets are installed on fingerboard in slightly curved shape, so that every string crosses all the frets in 90 degrees, i.e. to offer a minimum contact of string on a fret, and it makes the scale length of every string even while it actually varies on conventional fretting. The C.F.S. is a solution of fretting on a traditional guitar and bass and it offers clearer articulation and tones which give dimension when you play a cord and also cut through the mix when you play single notes.

Circle Fretting System

Compound radius fingerboard

The compound radius fingerboard has smaller (rounder) radius towards nut while larger (flatter) radius towards neck end i.e. similar to a shape of a cone.This allows for much easier chord playing at lower frets while having less stress, especially when bending strings at higher registers.

Compound Radius Fingerboard

664mm (26.1") long scale neck. 16mm (0.6") longer than the regular long scale works well with down tuned heavy gauge strings yet can be played like a regular guitar.

img_9538-664mm-long-scale

J-Standard fret edge treatment.

m_jil2ashde664g_opw_6

GOTOH®Magnum Lock tuners.

img_2244-gotoh-magnum-lock-tuners

FISHMAN®Fluence Modern 3-voice Humbuckers with 3-way toggle switch and Push-pull pots.

img_9563-fishman-pu-pot

Switching and Controls

202402fgn_pickup_jil3-de
