JMY3-EW1-DL-E

JMY3-EW1-DL-E

Specification

Construction Bolt-on Neck
Body Mahogany
Neck Maple/Walnut Asymmetrical Slim U-Shape
Fingerboard Ebony
Scale 25.5" (648mm)
Frets 24F Jumbo C.F.S.
Tuners GOTOH® SG381-07
Bridge GOTOH® 1996T
Tailpiece -
Hardware Color Cosmo Black
Pickup (Neck) FISHMAN® M36-AK1
Pickup (Middle) -
Pickup (Bridge) FISHMAN® M36-CK1
Controls 1Volume w/ Push-Pull SW (Voice 3-Split), 1Tone w/ Push-Pull SW (Voice 1/2), 3Way Toggle SW
Body Finish Open Pore Matte
Strings D'Addario EXL120 (.009-.042)
Others -
Accessories Premium Soft Case
Color ABF( Arctic Blue Flat)

Features

Circle Fretting System (C.F.S.)

All FGN guitars and basses come with a unique Circle Fretting System (C.F.S.). It was created by FGN based on an idea to offer better pitch and articulation than conventional guitars and basses. All frets are installed on fingerboard in slightly curved shape, so that every string crosses all the frets in 90 degrees, i.e. to offer a minimum contact of string on a fret, and it makes the scale length of every string even while it actually varies on conventional fretting. The C.F.S. is a solution of fretting on a traditional guitar and bass and it offers clearer articulation and tones which give dimension when you play a cord and also cut through the mix when you play single notes.

Circle Fretting System

5-pc Maple/Walnut asymmetrical slim neck with 24-fret Ebony fingerboard

img_2097-jmyblue-%e3%81%aa%e3%81%aa%e3%82%81neck

GOTOH®1996T double locking tremolo bridge.

img_4750-jmyblue-bridge

GOTOH®tuners and custom locking nut fitting C.F.S..

img_2095jmy-fgn-head

FISHMAN®Fluence Modern 3-voice Humbuckers with 3-way toggle switch and Push-pull pots.

img_2078-rev-fishman-fluence-modern-3-voice-humbuckers-with-push-pull-pots

Poplar Burl veneer top on Mahogany body with Black Pearloid binding.

img_2066-rev-jmy-blue-poplar-burl-veneer-top-on-mahogany-body

Switching System & Controls

202402fgn_pickup_jmy3
